Articulating Boom Lift 30′ Height x 20′ Reach, Electric Online

Description

Articulating Boom Lift 30′ Height x 20′ Reach, Electric

MODEL- GENIE..Z-30/20N RJ ARTICULATING BOOM LIFT

• DIMENSIONS- Stowed L= 17′ 5″/ W= 3′ 11″/ H= 6′ 7″
• WEIGHT- 14,220 lbs.
• WORKING HEIGHT- 35′ 2”
• PLATFORM HEIGHT- 29’ 2”
• HORIZONTAL REACH- 20’ 6”
• PLATFORM DIMENSIONS- 46″ x 30″
• PLATFORM CAPACITY- 500 lbs.
• PLATFORM ROTATION- 180°
• JIB ROTATION- 139° Vertical/ 180° Horizontal
• TURNTABLE ROTATION- 355°
• UP & OVER CLEARANCE- 12′ 8″
• TAIL SWING- Zero
• TURN RADIUS- 5′ 5″ Inside..10′ 7″ Outside
• TRAVEL SPEED- 2.8 MPH (Stowed)
• DRIVE- 2-Wheel
• TIRES- Non-Marking
• GRADEABILITY- 35% (Stowed)
• GROUND CLEARANCE- 3.5″
• POWER- 48 Volts DC (8) 6V 390 Amp hr. Batteries w/ 30 Amp Charger
