Hybrid Articulating Boom Lift 61′ Height x 40′ Reach, Diesel or Electric Supply

Description

Hybrid Articulating Boom Lift 61′ Height x 40′ Reach, Diesel or Electric

MODEL- JLG..M600JP ARTICULATING BOOM LIFT HYBRID

• DIMENSIONS- Stowed L= 33′ 4″/ W= 7′ 11″/ H= 8′ 4″
• WEIGHT- 16,050 lbs.
• WORK HEIGHT- 66′ 4″
• PLATFORM HEIGHT- 60′ 4″
• HORIZONTAL REACH- 44′ 5″
• PLATFORM DIMENSIONS- 30″ x 60″
• PLATFORM CAPACITY- 500 lbs.
• PLATFORM ROTATION- 180°
• JIB RANGE- 145° (+89, -56 Vertical)
• TURNTABLE ROTATION- 400°
• UP & OVER CLEARANCE- N/A
• TAIL SWING- 4′
• TURN RADIUS- Inside- 4’/ Outside- 15′ 4″
• TRAVEL SPEED- 3.0 MPH
• DRIVE- 4 Wheel
• TIRES- Non Marking Pneumatic 36 x 14-22.5
• GRADEABILITY- 45% -Stowed Only-
• GROUND CLEARANCE- 12″
• POWER- 48 Volts DC (8) 6 Volt 415 Amp Hr. Batteries
• ENGINE CHARGER- KUBOTA Diesel 6.7-HP…5 KW, 45 Amps
• FUEL CAPACITY- 13 Gallons
