Welding Fume Extractor – Small Online now

Description

Welding Fume Extractor – Small

MODEL- MILLER..FILTAIR 130 WELDING FUME EXTRACTOR

• DIMENSIONS- L= 12″/ W= 14″/ H= 27″
• WEIGHT- 46 lbs.
• CURRENT DRAW- 11 Amps @ 115 Volts 60 Hertz
• HOSE LENGTH- 8′ Standard…(Optional 17′ Hose extra)
• ELECT. CORD LENGTH- 20′
• NOZZLE OPENING- 1.25″ x 6″
• AIR FLOW- 0-132 CFM
• OPERATING TEMP. RANGE- -22 to 122 Deg. F.
• FILTER AREA- 31 Sq.Ft.
• SOUND LEVEL- 68.5 dBA @ 5′

DESCRIPTION- A Mobile, High Vacuum/Low Volume System That Uses A High Efficiency Cartridge Filter To Collect Airborne Weld Fume Particles. Weld Fumes Are Captured At The Source By A Hose Mounted Nozzle And Directed Through The Filter Where The Particles Are Removed From The Air. Compressed Air Removes The Particles From The Outside Of The Filter. The Particles Then Drop Into A Collection Tray Where They Are Collected For Disposal. The Extractor Includes: Collection Hose, Canisters, Flex Nozzle & Power Cord.

DO NOT ALLOW SPARKS OR BURNING MATERIALS TO ENTER THE HOSE & NOZZLE.

USE THE EXTRACTOR FOR THE INTENDED PURPOSE ONLY. IT IS NOT INTENDED TO REMOVE DUST OR FUMES FROM ANY OTHER SOURCE.
